Needle Detector, XR-8500

Electronic Detection Instrument, Cloth Inspection Solution, Food Inspecting Machine, Security Detection System, Metal Detector Manufacturer

XR-8500 needle detector is extensively applied in detecting magnetic metal impurities in cloth, toys, baby products, clothing accessories, shoes, socks, fabric, non-woven towels, blankets, gloves, and crafts, etc.

Jinzheng, a Chinese metal detector manufacturer, is committed to offering you the best security detection solutions.

Main Features
1. XR-8500 metal detector shows streamline exterior design. Carbon steel structure accompanied with painting treatment endows the equipment with stable performance and long service life.
2. Core part from Japan, conveyor belt from Netherlands, 32-bit chip, and digital circuit design with the newest international technique
3. Sensitivity of the detector is controlled by computer from 1 to 120 grade. Parameters are shown on LCD screen
4. Location of the broken needles or ferromagnetic metal is showed accurately
5. A snsing device is employed for the metal detection instrument to eliminate the interference from iron oxide
6. Quantity of the qualified, the unqualified, and the total is recorded intelligently. Detective products are separated out from the good ones
7. The load bearing frame is able to run stably with a load of 30kg
8. Unique color identification mode
9. Audible alert; rewind manually or automatically
10. Sensitivity is guaranteed by safety lock device

Technical Parameters
MODEL XR -8500
Detection approach electromagnetic induction, digital circuit processing
Sensitivity ≥ Fe Φ 0.8 ≥ Fe Φ 1.0 ≥ Fe Φ 1.2 ≥ Fe Φ 1.5 ≥ Fe Φ 2.0
Detection height 120 150 200 250 300
Detection width 500mm (customizable)
Detection adjustment 1-120 grade
Alerting method audible alert, shutdown, go backwards, and then restart
Power supply AC220V 50-60Hz
Pated output 120W
Machine Size L1850mm × W950mm × H1000mm
Net weight 280KG
